A complete picture of special-shaped hinges (what is the difference between full cover hinges, half 3

What is the difference between the full cover hinge and the half cover and side cover hinge? What are the hinges?

What are the differences and differences between full-cover hinges, half-cover hinges, and side-opening hinges? What are the types of hinges? What I recommend for you today is the knowledge of these aspects. From this, you can learn, first of all, It can be seen from their structural design that the so-called full cover may be more suitable for some special places, while other hinges are not the same. Another aspect and can also be classified according to the material, which can be classified according to the size and size. The detailed division includes some aluminum alloy steel materials, which are waterproof, moisture-proof and corrosion-resistant, and have a longer service life. There may also be other plastic hinges. They are relatively more cost-effective, and you can learn about them through the following.

the

1. What is the difference between full cover hinges and half cover and side cover hinges?

There are three types of door hinges: 45, 180, and 270. The angle indicates the inner angle after the cabinet is opened.

The full cover, half cover, and inlay of the hinge are determined according to the side panel of the cabinet, and the thickness of the side panel is generally 16-18MM.

Full cover: The door completely covers the side panel of the cabinet, and there is a gap between the two so that the door can be opened safely. Straight arm (0 mm) full cover door Straight arm (0 mm)

Half cover: In this case, two doors share a side panel. There is a minimum total gap required between them. The distance covered by each door is reduced accordingly, requiring the use of door hinges with curved arms. Middle curved (9.5mm) half cover door curved (9.5mm)

Responding door: In this case the door is inside the cabinet, next to the side panel of the cabinet. It also needs a clearance so that the door can be opened safely. Requires a hinge with a very curved hinge arm. Daqu (16mm) semi-recessed Daqu (16mm)

the

the

2. Types of hinges

Ordinary hinges: used for cabinet doors, windows, doors, etc. The materials are iron, copper and stainless steel. The disadvantage of ordinary hinges is that they do not have the function of spring hinges. After the hinges are installed, various touch beads must be installed. , otherwise the wind will blow the door panel.

Pipe hinge: also called spring hinge. It is mainly used for the connection of furniture door panels. It generally requires a plate thickness of 16-20 mm. The material is galvanized iron and zinc alloy. The spring hinge is equipped with an adjusting screw, which can adjust the height of the plate up and down, left and right, Thickness. One of its characteristics is that it can match the opening angle of the cabinet door according to the space. In addition to the general 90-degree angle, 127 degrees, 144 degrees, 165 degrees, etc. have corresponding hinges to match, so that various cabinet doors can be stretched accordingly. Spend.

Door hinge: It is divided into ordinary type and bearing type. The ordinary type has been mentioned before. The bearing type can be divided into copper and stainless steel in terms of material. From the current consumption situation, copper bearing hinges are mostly used. Because of its beautiful and bright style, moderate price, and equipped with screws.

Bearing hinge (copper): Each leaf shaft of the hinge is equipped with a one-way thrust ball bearing. The door switch is light and flexible, and it is mostly used on heavy-duty doors or special steel frame steel doors.

Inclined release hinge: This kind of hinge makes use of the inclined plane of the hinge and the weight of the door leaf to automatically close the door. It is mainly suitable for lighter wooden doors or half-section doors such as toilets.

The above recommendation is about the comparison between various hinges and the evaluation of the types. From this, we can know that the common hinges include full cover hinges, half cover hinges and side cover hinges. Three There are certain differences in their respective designs. In addition, suitable and reasonable hinges may be waterproof and moisture-proof stainless steel frame materials, or plastic materials. The corresponding cost performance and advantages are not the same. Suitable places There are also big differences. We should combine our actual needs and our respective budgets for reference, so as to achieve satisfactory results and ultimate goals.

What are the types of hinges? What are the common specifications of hinges?

Hinges are widely used in our lives. I believe that everyone is familiar with the material of hinges. Hinges are items that we will inevitably use when opening and closing doors. Whether it is a security door at home or a solid wood door indoors, Hinges are all required to be installed, but different doors use different types of hinges. Many users and friends only have a superficial understanding of hinges, so today we will explain them in detail in this article. Introduces some information about hinges.

What are the types of hinges?

Ordinary hinges. Mainly used for doors and windows. Ordinary hinge specifications: used for cabinet doors, windows, doors, etc. The materials are iron, copper and stainless steel. The disadvantage of ordinary hinges is that they do not have the function of spring hinges. After installing the hinge, you must install all kinds of touch beads, otherwise the wind will blow the door panel.

Pipe hinge. It is mainly used for the connection of furniture door panels, also called spring hinge. Pipe hinge specification page: also called spring hinge. It is mainly used for the connection of furniture door panels. It generally requires a plate thickness of 1620mm. The material is galvanized iron , Zinc alloy. The spring hinge is equipped with an adjusting screw, which can adjust the height and thickness of the plate up and down, left and right. One of its characteristics is that it can match the opening angle of the cabinet door according to the space. In addition to the general 90-degree angle, 127-degree, 144-degree , 165 degrees, etc. are matched with corresponding hinges, so that various cabinet doors have corresponding extensions.

Door hinge. It is divided into ordinary type and bearing type. The bearing type is divided into copper and stainless steel. Specifications of door hinge: it is divided into ordinary type and bearing type. The ordinary type has been mentioned before. The bearing type can be divided into copper and copper in terms of material. Quality, stainless steel. Judging from the current consumption situation, more copper bearing hinges are used, because of its beautiful and bright style, moderate price, and equipped with screws.

What are the common specifications of hinges?

There are many types of hinge specifications. The specifications of our commonly used doors and windows are 50.8*30*1, 100*60*1, 63*35*1, 101.6*76.2*2, 88.9*88.9*3, etc. Everyone is choosing when using hinges, pay attention to whether the surface plating of the hinges is fine and smooth, whether the edges of the spring pieces have been polished, and check whether the hinges are relatively light. If they are too heavy, they will not be conductive to rotation. The star-rated hotels are still common residential buildings, and it is difficult for people to see wooden "hukou". Most of the doors and windows of modern buildings use metal door hinges. The modern production of door hinges replaces the ancient "hukou". The ancient invention of "hushu" still remains on some old doors and windows of some ancient buildings and rural residential buildings in Guanzhong.

The above is all the content about the hinge that we introduced to you. In this article, we actually divide the content of the hinge into two parts. First, we introduce the classification of the hinge, because we are in a At the beginning, it was mentioned that different doors may use different hinges, so it is important to know the types of hinges. Then we also analyzed the general specifications of hinges. This part of knowledge is helpful for everyone to buy hinges by themselves. Still a great help.

1. According to the type of base, it can be divided into detachable type and fixed type;

2. According to the type of arm body, it is divided into two types: slide-in type and snap-in type;

3. According to the cover position of the door panel, it is divided into full cover (straight bend, straight arm) with a general cover of 18%, half cover (medium bend, curved arm) with a cover of 9%, and the built -in (large bend, large bend) door panels are all hidden inside.

Hinges are mainly installed on doors and windows, and hinges are more installed on cabinets. According to the classification of materials, they are mainly divided into stainless steel hinges and iron hinges; in order to let people enjoy better, hydraulic hinges (also known as damping hinges) have appeared. Its characteristic is that it brings a buffer function when the cabinet door is closed, which minimizes the noise caused by the collision with the cabinet body when the cabinet door is closed.

Extended information

Notes on hinge use:

1. Wipe gently with a dry soft cloth, do not use chemical cleaners or acidic liquids to clean, if you find black spots on the surface that are difficult to remove, wipe it with a little kerosene;

2. It is a normal phenomenon to make noise after a long time of use. In order to ensure the smooth and quiet pulley for a long time, you can regularly add some lubricating oil for maintenance every 2-3 months.

3. Prevent heavy objects and sharp objects from bumping and scratching.

4. Do not pull or pull hard during transportation, which may damage the hardware at the furniture joints.

Hinge type introduction Classification information description

When it comes to hinges, we all know that it is a basic accessory product, often called a hinge, but the hinges in our impression are generally similar, mainly installed in some cabinet doors and windows or ordinary wood In the door, it can play The role of making it easy for everyone to open and close. But in fact, the hinge can be classified in detail, such as ordinary hinges, pipe hinges or door hinges. In addition to classification according to shape, the field of use The difference in location and location also determines their names. When purchasing, we should refer to the differences between different hinges to understand.

1. Types of hinges

Ordinary hinges: used for cabinet doors, windows, doors, etc. The materials are iron, copper and stainless steel. The disadvantage of ordinary hinges is that they do not have the function of spring hinges. After the hinges are installed, various touch beads must be installed. , otherwise the wind will blow the door panel.

Pipe hinge: also called spring hinge. It is mainly used for the connection of furniture door panels. It generally requires a plate thickness of 16-20 mm. The material is galvanized iron and zinc alloy. The spring hinge is equipped with an adjusting screw, which can adjust the height of the plate up and down, left and right, Thickness. One of its characteristics is that it can match the opening angle of the cabinet door according to the space. In addition to the general 90-degree angle, 127 degrees, 144 degrees, 165 degrees, etc. have corresponding hinges to match, so that various cabinet doors can be stretched accordingly. Spend.

Door hinge: It is divided into ordinary type and bearing type. The ordinary type has been mentioned before. The bearing type can be divided into copper and stainless steel in terms of material. From the current consumption situation, copper bearing hinges are mostly used. Because of its beautiful and bright style, moderate price, and equipped with screws.

Bearing hinge (copper): Each leaf shaft of the hinge is equipped with a one-way thrust ball bearing. The door switch is light and flexible, and it is mostly used on heavy-duty doors or special steel frame steel doors.

Inclined release hinge: This kind of hinge makes use of the inclined plane of the hinge and the weight of the door leaf to automatically close the door. It is mainly suitable for lighter wooden doors or half-section doors such as toilets.

Cold storage door hinge: the surface is baked, the large size is made of steel plate, and the small size is made of cast iron. It is used for cold storage doors or heavy insulation doors.

Fan-shaped hinge: The thickness of the two sheets of the fan-shaped hinge is about half thinner than that of ordinary hinges, and it is suitable for various doors and windows that need to be rotated to open and close.

Silent hinge: also known as nylon washer hinge, when the door and window are opened and closed, the hinge is silent, and it is mainly used on the doors and windows of public buildings.

Single-flag hinge: The hinge is made of stainless steel, which is rust-resistant and wear-resistant, and easy to disassemble. It is mostly used on double-layer windows.

Window hinge: when installing, the two leaf plates with the mandrel should be installed on both sides of the window frame, and the two leaf plates without the mandrel should be installed on both sides of the window sash. One of the negative plates without the mandrel with a groove must be installed on the The grooved side of the window sash is convenient for loading and unloading of the window sash. It is used on the movable windows of factories, warehouses, houses, public buildings, etc.

Multifunctional hinge: when the opening angle is less than 75, it has the function of automatic closing. When it is at an angle of 75-90, it will be stable by itself, and if it is greater than 95, it will be automatically positioned. This hinge can be installed on the door instead of an ordinary hinge use on.

Anti-theft hinge: for ordinary hinges, when the shaft is pulled out, the door leaf can be removed. Anti-theft hinges can prevent the door leaf from being removed through the self-locking effect of the pins and pin holes on the two leaves of the hinge. It plays an anti-theft role and is suitable for residential doors.

Spring hinge: It can make the door leaf close automatically after opening. The single spring hinge can only be opened in one direction, and the double spring hinge can be opened in both directions. It is mainly used on the gate of public buildings.

Biaxial hinge: There are two kinds of biaxial hinges, left and right, which can make the door leaf open, close and disassemble freely. It is suitable for general door and window leaves.

From the above, we can know that there are many types of hinges, and the classification standards are also different, including starting from the purpose and appearance, or starting from the place and field of use, the types and names of hinges corresponding to different classification standards will also have different types. The difference, such as common door hinges, as the name implies, is used on some large doors to help open and close the hinges, that is, the so-called door hinges, and different classifications of hinges can be further detailed according to size and size. We should understand the parameters in this aspect when we study and refer to, and compare and get suitable and reliable suggestions and solutions.

Hinge Encyclopedia brings you the types of hinges

When you decorate a room, you need to use a lot of decoration materials, and you also need a lot of furniture to decorate the whole room, so that the room looks very beautiful. When you install doors and windows, you need to use a kind of object called a hinge. The lotus leaf is placed on the door and window The installation is very important, because the connection between the door and the door needs to be done with a hinge. There are many types of lotus leaves. When you choose, you may not know which one to choose because there are too many types. The following editor is for Let us introduce the types of hinges in detail!

What are the types of hinges?

List of Hinge TypesOrdinary Hinge

It is used for cabinet doors, windows, doors, etc. The materials are iron, copper and stainless steel. The disadvantage of ordinary hinges is that they do not have the function of spring hinges. After installing the hinges, various bumpers must be installed, otherwise the wind will Blow the door.

the

List of Hinge TypesPipe Hinges

It is also called spring hinge. It is mainly used for the connection of furniture door panels. It generally requires a plate thickness of 16-20 mm. The material is galvanized iron and zinc alloy. The spring hinge is equipped with an adjusting screw, which can adjust the height and thickness of the plate up and down, left and right. It One of the characteristics is that it can match the opening angle of the cabinet door according to the space. In addition to the general 90-degree angle, 127-degree, 144-degree, 165-degree, etc. have corresponding hinges to match, so that various cabinet doors have corresponding extensions.

the

List of Hinge Types - Door Hinge

It is divided into ordinary type and bearing type. The ordinary type has been mentioned before. The bearing type can be divided into copper and stainless steel in terms of material. From the current consumption situation, more copper bearing hinges are used because of their beautiful style. , bright, affordable, and equipped with screws.

the

Hinge specification and size:

Length*Width:

2 inches*1.5-1.8 inches

2.5 inches*1.7 inches

3 inches*2 inches

4 inches * 3 inches

5 inches*3-3.5 inches

6 inches*3.5-4

Note: inch means inch, 1 inch=25.4mm

the

Hinge installation method

The installation of the hinge is very simple, but at the same time, it is also necessary to pay attention to the differences in the style, type, and performance of the mother and child hinges. There are also certain differences in the installation. The built-in mother and child hinge is installed. It is necessary to leave a certain gap so that the door can be opened safely and flexibly. The full cover type mother hinge is installed, and the door is completely covered on the surface of the side panel of the cabinet, so it is necessary to pay attention to the size of the gap between the two. The half cover type mother hinge When installing two doors sharing the same side panel, there is a required small gap between the two, and the coverage distance of each door must be reduced accordingly.

I believe that after reading the introduction above, you should know what types of hinges are there? There are many types of lotus leaves. When choosing hinges, you must choose according to the type of your doors and windows. After installing the hinges, if you When there are some quality problems when using doors and windows, or you need to replace the doors and windows, you can remove the hinges and replace them with new doors and windows, which greatly saves the cost of maintenance and replacement. I hope that the editor's suggestions can help you choose Appropriate hinges can help you better repair doors and windows.

How about hidden hinges? Types of hinges?

What I recommend for everyone today is the evaluation of hidden hinges and the knowledge of hinge types. From this, we can know that, first of all, common hidden hinges are different from ordinary full cover hinges. Their design It is quite special. If it is installed between the cabinet door and the wooden door, it will not be easy to find later. On the other hand, this hidden hinge also means that we can use it when we stand outside the door and install the lock on the left, or the door lock is installed It can also be used on the right side, so this kind of hinge is more in line with the actual characteristics of humanization, and they are easy to install, suitable for invisible doors, and there are many adjustment directions. You can refer to the following for details. We will explain these few for you. Aspects of evaluation and presentation analysis.

the

1. How about the hidden hinge

1. Beautiful hidden device, without any exposed parts, beautiful and generous! 2. Adjustable three-dimensional adjustable, the adjustment direction is up and down, left and right, and bevel adjustment. 3. The durable hidden hinge is made of imported No. 3 zinc , the service life is as long as 30 years! 4. Easy to install. After the factory has opened the hole and installed it, you only need to take the hexagon wrench to the customer and screw it on. 5. Save after-sales costs. When the door sags, the customer can pass the Manually adjust the hinge to adjust the door, which greatly saves the cost of the manufacturer's door after-sales. Real estate forum, decoration forum, owner forum, P3 V9 O- M3 T"

2. Types of hinges

Ordinary hinges: used for cabinet doors, windows, doors, etc. The materials are iron, copper and stainless steel. The disadvantage of ordinary hinges is that they do not have the function of spring hinges. After the hinges are installed, various touch beads must be installed. , otherwise the wind will blow the door panel.

Pipe hinge: also called spring hinge. It is mainly used for the connection of furniture door panels. It generally requires a plate thickness of 16-20 mm. The material is galvanized iron and zinc alloy. The spring hinge is equipped with an adjusting screw, which can adjust the height of the plate up and down, left and right, Thickness. One of its characteristics is that it can match the opening angle of the cabinet door according to the space. In addition to the general 90-degree angle, 127 degrees, 144 degrees, 165 degrees, etc. have corresponding hinges to match, so that various cabinet doors can be stretched accordingly. Spend.

Door hinge: It is divided into ordinary type and bearing type. The ordinary type has been mentioned before. The bearing type can be divided into copper and stainless steel in terms of material. From the current consumption situation, copper bearing hinges are mostly used. Because of its beautiful and bright style, moderate price, and equipped with screws.

Bearing hinge (copper): Each leaf shaft of the hinge is equipped with a one-way thrust ball bearing. The door switch is light and flexible, and it is mostly used on heavy-duty doors or special steel frame steel doors.

Inclined release hinge: This kind of hinge makes use of the inclined plane of the hinge and the weight of the door leaf to automatically close the door. It is mainly suitable for lighter wooden doors or half-section doors such as toilets.

The above recommendations are about the characteristics of the hidden hinge and the precautions for installation. From this, we can know that this hidden hinge can be divided into adjustable hidden hinges and non-adjustable hidden lotus leaves, and the product is easy to install. It can be used on invisible doors, and there are a variety of adjustment directions for us to choose from. However, the specific operation effect in the later stage depends on the choice between the hidden door hinge parts. You can continue to understand the above, combined with the actual choice. A hidden spectrum and you can also refer to other classification knowledge of the hinge page for an in-depth understanding.

what is hinge

Hinge definition:

Hinge: also known as hinge. It is composed of a pair of metal leaves (or parts) connected by pivot pins, usually in two folds. It is a device by which two parts of furniture doors, covers or other parts that need to swing are connected and rotated.

Names of countries:

Chinese: hinge; hinge

German: Scharnier

English: Hinge

Spanish: Bisagra

French: Charnire (menuiserie)

Japanese: Butterfly

Classification of hinges:

1. Ordinary hinges: mainly used for cabinet doors, windows, doors, etc. The disadvantage of ordinary hinges is that they do not have the function of spring hinges. After installing the hinges, various bumpers must be installed, otherwise they will swing easily.

2. Special-shaped hinges: Compared with ordinary hinges, special-shaped hinges have the same function as ordinary hinges, but the structure is slightly different from ordinary hinges. It is mainly used in industrial products, such as flag-shaped hinges and spring hinges. types of pages.

The hinge is generally composed of the following accessories: 1. Hinge sheet; 2. Hinge shaft; 3. Hinge bearing (not necessary); 4. Hinge cap.

3. Common specifications of hinges: 2 inches (length 50mm), 2.5 inches (length 65mm), 3 inches (length 75mm), 4 inches (length 100mm), 5 inches (length 125mm), 6 inches (length 150mm).

English hinge cap term explanation:

FT---Flat tip (flat head) BT---Ball tip (ball head)

PT---Pagoda tip (pagoda head) GT---Acorn tip (acorn head)

CT---Crown tip (crown head) ST---Steeple tip (spire head)

(J IE Yang j ing is too hardware fittings factory HTTP://吹吹吹. Only then can it reflect the 1.HTML of .com/scripts/content/knowledge/knowledge Hi

Hinge Type Encyclopedia

The types of hinges include ordinary hinges, pipe hinges, and door hinges.

1. Ordinary hinge

In any era, ordinary represents the public and represents the trend at that time. In terms of doors, windows and furniture, the ordinary type is the most common, and the hinges corresponding to these ordinary furniture are also indispensable. Therefore, the most common type on the market The hinge type is the ordinary type, which does not have the function of a spring hinge.

2. Pipe hinge

This is a kind of spring hinge, which is to add a spring in the middle of the hinge to better control the opening and closing of doors, windows and furniture. It is worth mentioning that this kind of hinge is most commonly used in the connection of furniture door panels. The There are galvanized iron and zinc alloy hinges. The biggest feature is that the height and radian of up, down, left, and right can be adjusted, and the opening angle can even be determined according to the size of the room.

3. Door hinge

This is a highly targeted hinge, mainly used for the connection and rotation of the door leaf and the door frame. This type of hinge is made of copper or stainless steel, and it is also divided into ordinary type and bearing type. And the above mentioned Compared with the two hinges, the door hinge has the largest load-bearing capacity and is durable.

hinge

Hinge is also known as hinge, and its official name is hinge. It is often composed of two folds, which is a part that connects two parts of an object and enables it to move. Ordinary hinges are used for cabinet doors, windows, etc.; the materials are iron and copper. And stainless steel. The pipe hinge is also called a spring hinge; it is mainly used for the connection of furniture door panels, and it generally requires a plate thickness of 16 to 20 mm.
