How to install the hinge (how to install the hinge of the wardrobe door)

How to install the hinge of the wardrobe door

The first is the installation method. The installation method of the wardrobe door hinge is mainly selected according to the cover of the wardrobe door hinge. Full cover: If it is a wardrobe door that needs to cover all the side panels of the cabinet, then a space between the two should be reserved. A certain gap is convenient for the door to be opened safely. You can choose a wardrobe door hinge with a straight arm of 0mm. Half cover: Sometimes a large wardrobe is customized and two doors need to share a cabinet side panel. A minimum gap is required to ensure the load-bearing capacity of the two doors. At the same time, the coverage distance of each door should be reduced. It is necessary to install a wardrobe door hinge with a curved hinge arm. You can choose a door hinge with a middle curvature of about 9.5mm. : The wardrobe door is located in the cabinet. There needs to be a gap next to the side panel of the cabinet to facilitate the safe opening of the door. Then it is necessary to install a hinge with a very curved hinge arm. You can choose a door hinge with a large curvature of 16mm.

After the wardrobe door hinge is installed, it needs constant adjustment to make the door installed in the best position. 1. Adjustment of wardrobe door coverage distance: use a screwdriver to turn the screw to the right, the door needs to cover the distance becomes smaller (-), the wardrobe The door coverage distance becomes larger (). 2. Depth adjustment: it can be adjusted directly and continuously through the eccentric screw. 3. Height adjustment: the height can be adjusted precisely through the height-adjustable hinge base. 4. Spring force adjustment: In addition to the common three-dimensional adjustment, some relatively large hinges can also adjust the opening and closing force of the door. It is often used as the base point for the maximum force required for tall and heavy wardrobe doors. If it is applied to narrow doors and glass doors, it needs to be Adjust the spring force. By turning the hinge adjustment screw, the spring force can be reduced to 50%. When our wardrobe door has noise, it can be adjusted by turning the adjustment screw to the left to weaken the spring force. When our wardrobe door is not working well If the door is closed, you can turn the adjustment screw to the right to increase the spring force and make the door close better.

Wardrobe door hinge installation steps

. Use a screwdriver to loosen the screw of the door hinge counterclockwise; . Divide the wardrobe door hinge into two independent parts. We divide it into A and B. . Place part A on the door hinge as shown in the figure The corresponding position of the hole. . Use the supporting screws, and install part A on the door panel with a screwdriver. . Place the door hinge part B on the corresponding position on the side plate. Screw to adjust the spring force.

How to install the hinge of the upper opening

Consultation Record · Answered on 2021-10-28

How to install the hinge of the upper opening

1. Prepare a screwdriver, pliers and a hammer, and determine the installation position and quantity. 2. Fasten with screws, first make a slot on one side, then place the leaf plate in the slot, and finally fix the hinge with matching screws to ensure The screw and the door cover are vertical. If there is a slight tilt problem, it is likely to be squeezed. Finally, check whether the door is relatively flexible to open and close. If there is no problem, tighten the screw.

The installation method of the 45 degree hinge is as follows:

The 45-degree hinge position is generally installed about a quarter of the distance from the top and bottom of the door to ensure balanced force. Then fasten it with screws, first make a slot on one side, then place the leaf plate in the slot, and finally use screws to fasten the hinge. Fix the page to ensure that the screws and the door casing are vertical.

If there is a slight tilt problem, it is likely to be squeezed. Finally, check whether the opening and closing of the door is relatively flexible. If there is no problem, just tighten the screws.

Hinge installation precautions

When installing the hinges, in order to ensure that each one can bear the force evenly, they should be installed at the position where the side edge of the door leaf is 1/10 of the distance from the upper and lower sides of the door leaf height.

At the same time, in order to ensure the accuracy of the hinge installation, when measuring the hinge installation position on the door frame and door leaf, whether it is the upper hinge or the lower hinge, it should be measured from the upper part of the door frame or door leaf.

Of course, there are some other details worthy of attention, that is, the width of the hinge must be smaller than the thickness of the door leaf, and its long side edge should be aligned with the back of the door leaf, so that the installation is beautiful and does not affect the use. At the same time, in order to prevent installation deviation , the mark should be marked on the back of the door leaf in advance.

180 degree double spring hinge installation method

answer

1. Preparation before installation: Before installing any hinge, make all preparations. This is the basic quality and common sense that a professional installer should possess. For example, check the matching degree between the spring hinge and the cabinet fan and cabinet frame, and check whether the type, specification and accessories of the hinge are suitable. 2. Determine the installation position of each leaf board: two leaf boards with some hinges It is asymmetrical. In this case, it is necessary to determine which leaf board should be placed on the cabinet frame and which leaf board should be placed on the cabinet fan. position, and then slot according to the position of the page, and the depth of the slot should be consistent with the thickness of the page. If you choose a spring hinge that does not need to be drilled, this step can be omitted. 4. Fix the leaf plate: The groove is also opened, and the next thing to do is to put the leaf plate in the groove, and then use welding or It's fixed with screws. In the process of fixing, it is necessary to avoid the tilting of the leaf board.

How to install the hinge on the color steel skin

Install the hinge on the color steel skin: tighten the hinge with matching screws during the tightening of the hinge.

In the installation process of color steel doors, hinges are needed. Hinges, also known as hinges, are mechanical devices used to connect two solids and allow relative rotation between them. If you cant install them yourself, it is recommended to find a professional .

The correct installation method of the hinge

Prepare the relevant installation tools, and determine the specific installation location and installation quantity. In general, the hinge needs to be installed at the top of the door and a quarter of the bottom of the door, so as to ensure that the door panel can be balanced. Use screws Fix the hinges on the door panel and cabinet body.

Before fixing, you should first make a slot on one side, then put the leaf plate into the slot, and then use screws to fix the hinge. During the fixation, you must ensure that the door cover and the screws are kept in a vertical state. Try to open it And close the door panel to see if it can be used flexibly and whether there will be noise. After confirming that there is no problem, tighten the screws thoroughly to make it more firmly installed.

There are many kinds of hinge materials. Under normal circumstances, steel hinges are not suitable for installation in places with relatively humid environments. Otherwise, after a long time of use, the hinges will rust, and the corrosion resistance of copper hinges It will be better, so it is widely installed in the kitchen or bathroom area.

Do you know how to install spring hinges with hooks?

1. Before installation, check whether the hinges match the door and window frames and leaves.

2. Check whether the hinge groove matches the height, width and thickness of the hinge.

3. Check whether the hinge and the screws and fasteners connected to it are matched.

4. The connection method of the hinge should match the material of the frame and leaf, such as the hinge used for the steel frame wooden door, the side connected to the steel frame is welded, and the side connected to the wooden door leaf is fixed with wood screws.

5. When the two leaf plates of the hinge are asymmetrical, it should be identified which leaf plate should be connected to the fan, which leaf plate should be connected to the door and window frame, and the side connected to the three sections of the shaft should be fixed to the frame , the side connected to the two sections of the shaft should be fixed to the frame.

6. When installing, it should be ensured that the shafts of the hinges on the same leaf are on the same vertical line, so as to prevent the door and window leaves from springing up.

How to install the cabinet door hinge, the installation method of the cabinet door hinge

There is another name for cabinet door hinges called hinges. This is mainly used to connect our cabinets and our cabinet doors. It is also a common hardware accessory. Cabinet door hinges are used in our cabinets. Time is very important. We open and close many times a day, and the pressure on the door hinge is very great. Many people don't know how to install it after buying it. Today I will introduce you to the installation of the cabinet door hinge. method.

the

Introduction to the installation method of the cabinet door hinge

Installation method and method

Full cover: The door completely covers the side panel of the cabinet body, and there is a certain gap between the two, so that the door can be opened safely.

Half cover: Two doors share a cabinet side panel, there is a required minimum gap between them, the coverage distance of each door is reduced, and a hinge with hinge arm bending is required. The middle bend is 9.5MM.

Inside: The door is located inside the cabinet, beside the side panel of the cabinet body, it also needs a gap to facilitate the safe opening of the door. A hinge with a very curved hinge arm is required. The big bend is 16MM.

First of all, we need to install the hinge cup. We can use screws to fix it, but the screws we choose need to use flat countersunk head chipboard self-tapping screws. We can use this kind of screw to fix the hinge cup. Of course, we can also use Tool-free, our hinge cup has an eccentric expansion plug, so we use our hands to press it into the pre-opened hole of the entry panel, and then pull the decorative cover to install the hinge cup, the same unloading The same is true of time.

After the hinge cup is installed, we still need to install the hinge seat. When we install the hinge seat, we can also use screws. We still choose particleboard screws, or we can use European-style special screws, or some pre-installed special expansion plugs. Then the hinge seat can be fixed and installed. There is another way for us to install the hinge seat is the press-fitting type. We use a special machine for the hinge seat expansion plug and then press it in directly, which is very convenient.

Finally, we need to install the cabinet door hinges. If we dont have tools for installation, it is recommended that you use this tool-free installation method for cabinet door hinges. This method is very suitable for quick-installed cabinet door hinges, which can be used The way of locking, so that it can be done without any tools. We first need to connect the hinge base and the hinge arm at our lower left position, and then we buckle down the tail of the hinge arm, and then Gently press the hinge arm to complete the installation. If we want to open it, we only need to press lightly on the left empty space to open the hinge arm.

We use a lot of cabinet door hinges, so after a long time of use, it is inevitable that there will be rust, and if the cabinet door is not closed tightly, then we'd better replace it with a new one, so that we can use it with more confidence.

Cabinet door hinge installation method:

1. Minimum door margin:

First of all, we need to determine the minimum door margin between the cabinet doors to be installed, otherwise the two doors are always "fighting", which is not beautiful and practical. The minimum door margin depends on the type of hinge, hinge cup margin and cabinet Select the value based on the thickness of the door. For example: the thickness of the door panel is 19mm, and the edge distance of the hinge cup is 4mm, so the minimum door edge distance is 2mm.

2. Selection of the number of hinges

The number of cabinet links selected should be determined according to the actual installation experiment. The number of hinges used for the door panel depends on the width and height of the door panel, the weight of the door panel, and the material of the door panel. For example: a door panel with a height of 1500mm and a weight between 9-12kg, 3 hinges should be used.

3. Hinges adapted to the shape of the cabinet:

The cabinet with two built-in rotatable pull baskets needs to fix the door panel and the door frame at the same time. The most important thing is that the built-in pull basket determines its opening angle to be very large, so the curvature of the hinge must be large enough to ensure that it can Freely open the cabinet door to a suitable angle, and conveniently take and place any items.

4. Selection of hinge installation method:

The door is divided according to the position of the door side and the side of the side panel, and there are three installation methods: full cover door, half cover door and embedded door. The full cover door basically covers the side panel; the half cover door covers the side panel. The half of the board is especially suitable for cabinets with partitions in the middle that need to install more than three doors; the embedded doors are installed in the side boards.

The above is the installation method of the cabinet door hinge introduced to you. Are you clear? In fact, the installation of the cabinet door hinge is very simple, we can install it without tools, but if you dont know what to do after reading the above How to install it, I suggest that you better find someone to install it, so that you can be more assured, and it will not cause any problems in your life due to poor installation.

How to install the cabinet door hinge Installation tips for the cabinet door hinge

1. Preparation tools

Prepare special installation tools before installation, such as tape measure/level for measuring, carpenters pencil for line drawing and positioning, woodworking hole saw/pistol drill for opening holes, screwdriver for fixing, etc.

2. Line drawing positioning

First use the installation measuring board or woodworking pencil to mark the position (the drilling edge distance is generally 5mm), and then use a pistol drill or woodworking hole opener to drill a 35mm hinge cup installation hole on the door panel, and the drilling depth is generally 12mm .

3. Fixed hinge cup

Insert the door hinge into the hinge cup hole on the door panel and fix the hinge cup with self-tapping screws.

4. Fixed base

After the cabinet door hinge is inserted into the cup hole of the door panel, open the cabinet door hinge, then insert and align the side panels, and fix the base with self-tapping screws.

5. Debugging effect

After the installation is completed, open and close the cabinet door to try the effect, if the effect is not good, it should be adjusted in time.

How to install the aircraft hinge

Ordinary hinges: used for cabinet doors, windows, doors, etc. The materials are iron, copper and stainless steel. The disadvantage of ordinary hinges is that they do not have the function of spring hinges. After the hinges are installed, various touch beads must be installed , otherwise the wind will blow the door panel.

Pipe hinge: also called spring hinge. It is mainly used for the connection of furniture door panels. It generally requires a plate thickness of 16-20 mm. The material is galvanized iron and zinc alloy. The spring hinge is equipped with an adjusting screw, which can adjust the height of the plate up and down, left and right , Thickness. One of its characteristics is that it can match the opening angle of the cabinet door according to the space. In addition to the general 90-degree angle, 127 degrees, 144 degrees, 165 degrees, etc. have corresponding hinges to match, so that various cabinet doors can be stretched accordingly. Spend.

Door hinge: It is divided into ordinary type and bearing type. The ordinary type has been mentioned before. The bearing type can be divided into copper and stainless steel in terms of material. From the current consumption situation, copper bearing hinges are mostly used. Because of its beautiful and bright style, moderate price, and equipped with screws.

Other hinges: there are glass hinges, countertop hinges, and flap hinges. Glass hinges are used to install frameless glass cabinet doors, and the thickness of the glass is required to be no more than 5-6 mm.

How to install the door hinge, the style and size of the hinge

Doors are installed in each of our homes, which can protect our privacy and the safety of our homes very well, and bring a lot of convenience to our lives. However, the door hinges cannot be used to play their due role. Small sight. But readers, are you familiar with door hinges? In fact, door hinges are often encountered in daily life. Next, lets get to know them together with the introduction of the editor. So, how about door hinges? Install?

the

How to install the door hinge

Before installation, check whether the hinge matches the door and window frame and leaf, check whether the hinge groove matches the height, width, and thickness of the hinge, check whether the hinge is matched with the screws and fasteners connected to it, and whether the hinge of the villa door The connection method should match the material of the frame and leaf. For example, the hinge used for the steel frame wooden door, the side connected to the steel frame is welded, and the side connected to the wooden door leaf is fixed with wood screws.

In the case that the two leaf plates of the door hinge are asymmetrical, it should be identified which leaf plate should be connected to the fan, which leaf plate should be connected to the door and window frame, and the side connected to the three sections of the shaft should be fixed to the frame. The side connected to the two sections of the shaft should be fixed with the doors and windows. When installing, it should be ensured that the shafts of the hinges on the same leaf are on the same vertical line to prevent the doors and windows from bouncing.

the

Hinge style and size

There are many styles, specifications and sizes of hinges. From the style alone, they can be divided into more than a dozen types such as ordinary hinges, H hinges, window hinges, and cross hinges, not to mention the choice of each hinge size. .Although there are so many hinge styles, there are several kinds of hinges that are often used in home decoration. The most common is the 4-inch hinge, that is, 4*3*3 hinge, 4 means the length is 10cm, 3 is Refers to the width of 3cm, and 3 refers to the thickness of 3mm. This kind of ordinary hinge is most commonly used in various room doors, including study doors, bedroom doors, bathroom doors, etc. In addition to ordinary hinges, the other one can be opened without slotting. Letter hinges that can be installed directly are also very popular, but because of their different structures, they are more suitable for use on lightweight doors and windows, such as paint-free doors, bathroom doors, etc.

the

Choice of hinges for different doors

The hinges of the door need to use anti-theft hinges, which are usually matched with the door and do not need to be purchased again. The hinges used for cabinet doors can use long rows of hinges. One hinge of this kind is 1.8m long. It can install 3 cabinet doors, and you can also choose to use pipe hinges or ordinary small hinges. The installation of pipe hinges will be more convenient, but the functions are relatively small. There are many sizes of pipe hinges, plus the full cover (hinge There is a frame next to it), half cover, no cover, etc. You need to measure the size of the cabinet at home and choose it accurately. If you want to install a hidden door at home, you need to use a cross hinge, which can be completely hidden after closing the door , so it is also called a hidden hinge. When choosing the hinge size, it can be determined according to the thickness of the door and the door frame. Usually, the cross hinge has a variety of sizes such as 45mm, 70mm, and 95mm. If it cant be installed, it is best to measure the thickness of the door before making a choice. The hinges of doors and windows, whether it is size or style, should be adjusted according to the specific position and function of the doors and windows. During the decoration process, absolutely not In order to save time and money, all doors and windows use hinges of uniform specifications. If you choose hinges well, it will be smoother and more convenient to use doors and windows in your future life.

There are so many door hinges introduced by Xiaobian today. I believe that everyone has a certain understanding of door hinges. When choosing door hinges, you may wish to consider these methods introduced by Xiaobian. Door hinges Hinge brings a lot of convenience to our life and protects our home and privacy. You need to understand the installation method of door hinges. In fact, knowing more about Hinge is also very helpful for our life. I hope my introduction It can help readers and friends.
