Types of drawer tracks (what are the classifications of plastic steel door and window slide rails?

The classification of plastic steel door and window slide rails can be divided into three main categories: roller drawer slide rails, steel ball drawer slides, and gear-type drawer slides.

1. Roller drawer slide rails: This type of slide rail has been around for a long time and is considered the first generation of silent drawer slide rails. It is composed of a pulley and two rails, and while it can meet the daily push and pull needs, it has poor bearing capacity and does not have the function of buffering and rebounding. Roller slide rails are often used on computer keyboard drawers and light drawers.

2. Steel ball drawer slides: Steel ball slides are commonly used in modern furniture and are gradually replacing roller slide rails. They are usually two-section or three-section metal slides that are installed on the side of the drawer. Steel ball slide rails are known for their smooth sliding and large load-bearing capacity. They can also have the function of cushioning closing or pressing and rebounding to open.

Types of drawer tracks (what are the classifications of plastic steel door and window slide rails?
 1

3. Gear-type drawer slides: This category includes hidden slides, horse-riding drawer slides, and other slides that are considered medium and high-end. Gear-type drawer slides use a gear structure to achieve smooth and synchronous movement. They also have the function of cushioning closing or pressing rebound opening. However, gear-type drawer slides are relatively more expensive and less popular than steel ball slide rails in modern furniture.

In terms of installing drawer slide rails, it is important to choose the appropriate type based on the specific drawer. Generally, three-section hidden slide rails are used for most household drawers. To install the slide rails, first determine the length of the drawer and the depth of the counter, and select the corresponding size of slide rail. Then, assemble the five boards of the drawer and screw them together. The drawer panel should have a card slot that aligns with the adjustment nail holes on the installed slide rail. Finally, secure the slide rail to the cabinet by screwing plastic holes on the side panel of the cabinet and fixing the slide rail with small screws.

To distinguish between a two-section drawer slide rail and a three-section drawer slide rail, there are a few key differences to consider. Firstly, the structure of the two-section drawer slide rail consists of an outer rail and an inner rail, while the three-section drawer slide rail includes an outer rail, a middle rail, and an inner rail. Secondly, the width of the two-section slide rail is generally 17mm, 27mm, or 35mm, while the width of the three-section slide rail is typically 45mm. Thirdly, the stroke, or the length the slide rail can be pulled out, differs between the two types. A two-section drawer slide rail can be pulled out to about 3/4 of the drawer, whereas a three-section slide rail allows for the full extension of the drawer. Finally, the three-section slide rail tends to be more convenient to use because of its ability to fully extend, making it easier to access the contents of the drawer.

In terms of durability, there are several reputable brands that provide high-quality drawer slide rails. Some well-known brands include Gute, Dinggu, and German Hfele. These brands offer slide rails that are reliable, durable, and have good after-sales service. When selecting a brand, it is essential to consider factors such as product quality, reputation, and customer reviews.

In conclusion, the classification of plastic steel door and window slide rails includes roller drawer slide rails, steel ball drawer slides, and gear-type drawer slides. Each type has its own advantages and is suitable for different applications. When selecting drawer slide rails, it is important to choose the appropriate type based on the specific drawer and consider factors such as smoothness of sliding, load-bearing capacity, and price. Reputable brands, such as Gute, Dinggu, and German Hfele, are recommended for their high-quality and durable products.
