Efficient Storage Solution with TALLSEN TH5090 the whole hinge Cabinet hinge
TALLSEN TH5090 HINGE carries designer's unique technology, creating a hinge that allows the cabinet door to open 90 degrees. The TH5090 hinge is equipped with a four-hole base, and the arm body adopts a semi-open classic tail buckle design, which is simple but stable; The 1.0mm thicker design of the base and arm body is enough to support cabinet doors weighing up to 10kgs without deformation, and the service life can reach 10 years;
TALLSEN adheres to international advanced production technology, authorized by ISO9001 quality management system, Swiss SGS quality testing and CE certification,ensure that all products comply with international standards.
Product Description
|
Name |
Tallsen th5090 hinge |
|
Finish |
Nickel plated |
|
Type |
Inseparable hinge |
|
Opening angle |
105° |
|
Diameter of hinge cup |
35mm |
|
Product type |
One way |
|
The depth adjustment |
-2mm/+3.5mm |
|
Base adjustment(up/down) |
-2mm/+2mm |
|
Door thickness |
14-20mm |
|
Package |
2 pcs/poly bag, 200 pcs/carton |
|
Samples offer |
Free samples |
Product Description
TALLSEN TH5090 the whole hinge is made of high-quality cold-rolled steel from Shanghai Baosteel, which is hard, durable and stable in performance; Double electroplating on the surface of the hinge, the thickness can reach 3mm, 1.5mm copper plating, 1.5mm nickel plating, which greatly improves the anti-corrosion and anti-rust performance of the hinge, and the service life can reach 10 years.
It is suitable for furniture in different environments such as bathrooms, bedrooms, and kitchens; Each batch of cabinet hinges passed the 48-hour neutral salt spray test and level 8, anti-corrosion and anti-rust. And passed 50,000 opening and closing tests, with a service life of up to 20 years.
Suitable for door panels with a thickness of 14-21mm, wider application scenarios ex. Wardrobe, Kitchen cabinet,Bathroom cabinet etc.
Installation Diagram
Product Details
Product Advantages
● Superior raw material from Shanghai Baosteel
● 3MM double-layer electroplating
● Cabinet door to open 90 degrees
● 48 hours neutral salt spray test level 8
● 50000 opening and closing tests
● 20 years service life
