Drawer slide rail installation video (how to install wardrobe drawer slide rails drawer slide rail i

How to install wardrobe drawer slide rails How to install drawer slide rails

Drawer slide rail installation video (how to install wardrobe drawer slide rails drawer slide rail i 1

The first step in the installation of drawer slides: understand the composition of drawer slides

1. The smallest part of the drawer slide rail - the movable rail and the inner rail

2. The middle part of the drawer slide rail - middle rail

3. The end part of the drawer slide rail - the fixed rail is the outer rail

Drawer slide installation step two: remove all inner rails

Before installing the drawer slide rails, it is necessary to disassemble the inner rails of all the drawer slide rails (ps: the outer rails and the middle rails do not need to be disassembled directly). The disassembly method refers to pressing the inner circle of the circlip and gently pulling the inner rails of the drawer. Buckle the circlip toward the body, and then pull out the inner rail, pay attention to remove the inner rail and be careful not to deform the guide rail.

The third step of the drawer slide installation: install the main body of the drawer slide

Install the main body of the drawer slide rail on the side of the cabinet body. Generally, the panel furniture cabinet body will have ready-made holes for easy installation. Install the main body of the drawer slide rail side panels, it is best to install them before starting to assemble the furniture).

The fourth step of the drawer slide installation: install the inner rail of the drawer slide

Then install the inner rail of the drawer slide rail on the outside of the drawer with an electric screw drill. Note that there are spare holes for adjusting the front and rear positions of the drawer on the inner rail of the drawer. The front and rear positions of the drawer can be adjusted through these holes in the installation position.

The fifth step of the drawer slide rail installation: connect the drawer rails to realize the drawer installation

The last step is to embed the drawer into the cabinet body, press the snap springs on both sides of the inner rail of the drawer slide rail with your fingers, and then align the main body of the slide rail and slide it into the cabinet body in parallel.

How to install drawer slide rails, drawer slide rail installation steps and methods

Drawer slide rail installation steps:

1. First fix the five boards of the assembled drawer, screw on the screws, the drawer panel has a card slot, and there are two small holes in the middle for installing the handle;

2. To install the drawer slide rails, you first need to disassemble the rails. The narrow ones are installed on the drawer side panels, and the wide ones are installed on the cabinet body. To distinguish before and after;

3. Install the cabinet body. Screw the white plastic hole on the side panel of the cabinet body first, and then install the wide track removed from above. One slide rail is fixed with two small screws one at a time. Both sides of the body must be installed and fixed.

Precautions for installing drawer slide rails:

1. The first is the choice of size. Generally speaking, the length of the slide rail of the drawer should be the same as the length of the drawer drawer. If the slide rail is too short, the drawer cannot reach the maximum opening and closing. If it is too long, it will cause failure. Install.

2. For the drawer slides, the installation is relatively simple. The key is how to dismantle them. In some pictures of how to disassemble the drawer slides, there are more detailed dismantling steps. Through these steps, it can be dismantled very well. , so if it is time to install, then you can reverse the thinking and restore it step by step from the dismantling steps, then you will know how to install the drawer slides.

How to install the keyboard drawer slide rail

Proceed as follows:

1. Move the small plastic sheet (usually black) in the middle of the rail to one side to separate the rail into two parts.

2. Put the part without balls (with small plastic sheet) on the drawer with wood screws (note the direction);

3. Put the part with the ball (with the rail) on the table with wood screws (note the direction);

4. Move the small plastic sheet (usually black) in the middle of the drawer rail to one side and push the drawer in.

How to install the drawer rails

Disassembly method:

Open the drawer to the end and find the thin black dial at the junction of the two slide rails. It is the pointed plastic in the picture. If the position is higher, push down. Press, pull the guide rail back and it will be disassembled.

How to install drawer rails

1: Speaking of the installation method of the drawer guide rail, the length of the drawer guide rail must be the same as the length of the drawer, that is, match. If the length matches, it generally shows that the drawer

The height dimension is measured accurately, and then the measured dimension is drawn on the corresponding wooden board through the ink line.

2: After step 1 is ready, it is necessary to install it. According to the several screw holes given by the drawer guide rail, select the corresponding screw to fix it. When fixing the screw, be sure

Both sides must be fixed, and the wooden boards on both sides of the drawer must be fixed. After fixing, put the drawer into the guide rail and drag it to test whether the installation is successful.
