Product details of the white cabinet hinges
Quick Overview
Tallsen white cabinet hinges is delicately crafted by our adept professionals by using modern technology. Perfect quality is our commitment to every customer. Tallsen's white cabinet hinges can be applied to different fields. The product is increasingly used in the market.
Product Information
Compared with other similar products in the market, Tallsen's white cabinet hinges is provided with the following outstanding advantages.
Soft Closing Damper Full Overlay Cabinet Hinges
Clip-on 3d adjustalbe hydraulicdampimg hinge(one-way)
Name | Soft Closing Damper Full Overlay Cabinet Hinges |
Type | Clip-on One Way |
Opening angle | 100° |
Diameter of hinge cup | 35mm |
Material | Stainless Steel, Nickel Plated |
Hydraulic Soft closing | yes |
The depth adjustment | -2mm/ +2mm |
Base adjustment (up/down) | -2mm/ +2mm |
Door coverage adjustment | 0mm/ +6mm |
Suitable Board Thickness | 15-20mm |
Depth of Hinge Cup | 11.3mm |
Hinge Cup Screw Hole Distance | 48mm |
Door Drilling Size | 3-7mm |
Height of mounting plate | H=0 |
Package | 2pc/polybag 200 pcs/carton |
PRODUCT DETAILS
TH3309 Soft Closing Damper Full Overlay Cabinet Hinges.They require very little alignment and make the job much easier when you have a few hinges to fit. | |
The soft closing function is one of the best indicators of the quality of the hinges. The soft closing feature prevents all disturbing noises from the kitchen and extends the lifetime of the doors, cabinets, and hinges. | |
The clip-on hinge is the easiest and quickest to fit, without any tools. It is ideal for doors requiring multiple hinges to be fitted this is because you simply line the hinge up with the mounting plate and push it on in one simple movement, it will then clip on to be connected to your mounting plate. |
INSTALLATION DIAGRAM
Tallsen is a home hardware enterprise integrating R&D, production and sales. Tallsen has a 13,000㎡modern industrial area, a 200㎡marketing center, a 200㎡product testing center, a 500㎡ experience exhibition hall, a 1,000 ㎡logistics center. Tallsen is always committed to creating the industry's superior quality household hardware products.
FAQ:
The soft closing function is one of the best indicators of the quality of the hinges. Each cabinet door hinge features a built-in damper that creates a self-closing motion. The soft closing feature prevents all disturbing noises from the kitchen and extends the lifetime of the doors, cabinets, and hinges. What will the soft-closing feature give us:
1-Silent open and closing.
2-Minimize disturbing noises.
3-Extend the lifetime of cabinets and doors.
4-Provide a comfortable home environment.
5-The suitable closing speed which could protect your hands.
